The following statements are supported :
• Decision and structures
IF, THEN, ELSE, ELSEIF, END IF, DO, LOOP, WHILE, WEND, UNTIL, EXIT DO, EXIT WHILE, FOR, NEXT, TO, DOWNTO, STEP, EXIT FOR, ON .. GOTO/GOSUB, SELECT, CASE.
• Input and output
PRINT, INPUT, INKEY, PRINTHEX, INPUTHEX, LCD, UPPERLINE, LOWERLINE,DISPLAY ON/OFF, CURSOR ON/OFF/BLINK/NOBLINK, HOME, LOCATE, SHIFTLCD LEFT/RIGHT, SHIFTCURSOR LEFT/RIGHT, CLS, DEFLCDCHAR, WAITKEY, INPUTBIN, PRINTBIN, LCDHEX, OPEN, CLOSE, DEBOUNCE, SHIFTIN, SHIFTOUT.
• Numeric functions
AND, OR, XOR, INC, DEC, MOD, NOT, ABS, BCD.
• I2C
I2CSTART, I2CSTOP, I2CWBYTE, I2CRBYTE, I2CSEND and I2CRECEIVE.
• 1WIRE
1WWRITE, 1WREAD, 1WRESET.
• SPI
SPIINIT, SPIIN, SPIOUT.
• Interrupt programming
ON INT0/INT1/TIMER0/TIMER1/SERIAL, RETURN, ENABLE, DISABLE, PRIORITY SET/RESET, COUNTERx, CAPTUREx, INTERRUPTS, CONFIG, START, LOAD.
• Bit manipulation
SET, RESET, ROTATE, BITWAIT.
• Variables
DIM, BIT , BYTE , INTEGER , WORD, LONG, SINGLE, STRING , DEFBIT, DEFBYTE, DEFINT, DEFWORD.
• Miscellaneous
REM, ' , SWAP, END, STOP, CONST, DELAY, WAIT, WAITMS, GOTO, GOSUB, POWERDOWN, IDLE, DECLARE, CALL, SUB, END SUB, MAKEDEC, MAKEBCD, INP,OUT, ALIAS, DIM , ERASE, DATA, READ, RESTORE, INCR, DECR, PEEK, POKE, CPEEK, GETRC5.
• Compiler directives
$INCLUDE, $NOINIT, $BAUD and $CRYSTAL, $OBJ, $SERIALINPUT, $SERIALOUTPUT, $ROMSTART, $RAMSIZE, $RAMSTART, $MONSTART, $IRAMSTART, $DEFAULT XRAM, $ASM-$END ASM, $LCD.
• Conditional compilation
#IF, #ELSE, #ENDIF
• String manipulation
STRING, SPACE, LEFT, RIGHT, MID, VAL, HEXVAL, LEN, STR, HEX, LCASE, UCASE
To make a program takes just a few steps :
• Write the program in BASIC
• Compile it to fast machine binary code
• Test the result with the integrated simulator(with additional hardware you can simulate the hardware too)
• Program the chip with one of the integrated programmers.
(hardware must be purchased separately)
